MK Battery ES Series — 12V Small AGM Battery (1.2–14 Ah)

12V sealed AGM batteries for medical devices and small mobility applications. F1 or F2 faston tab terminals depending on capacity.

Capacity options:

• ES1.2-12: 1.2 Ah, 1.21 lbs (F1)
• ES3-12: 3 Ah, 2.87 lbs (F1)
• ES5-12: 5 Ah, 4.18 lbs (F1 or F2)
• ES7-12: 7.2 Ah, 5.28 lbs (F1 or F2) — used in some Frank Mobility E-Fix variants
• ES9-12: 9 Ah, 5.94 lbs (F1 or F2)
• ES10-12S: 10 Ah, 7.24 lbs (F2) — Pride Bobcat X, Pride GoGo ES 2, Shoprider Hero/Echo Folding
• ES12-12: 12 Ah, 8.84 lbs (F2)
• ES14-12: 14 Ah, 9.68 lbs (F2) — Electric Mobility Liteway series

Terminals: F1 = FASTON No. 187  |  F2 = FASTON No. 250

Recommended charger: LS24/2A

About MK Sealed AGM batteries:

• Absorbed Glass Mat (AGM) construction — electrolyte held in fiberglass mats
• Sealed valve-regulated lead acid (VRLA) — maintenance-free, non-spillable
• Best suited for lighter-duty mobility applications
• F.A.A., IATA, and UPS approved for shipping

Note from MK Battery: "MK Battery considers AGM batteries to be suitable for lighter duty mobility equipment only. AGM batteries used in more robust applications such as complex rehab mobility devices, where daily deep discharges are the norm, may void the warranty." For heavy-duty applications, consider the equivalent Gel battery instead.

Supplier reference: MK Battery ES series
